typedef struct{        //Simple structure for a thread
 unsigned int esp0;   //Stack for kernel
 unsigned int esp3;   //Stack for process
} Thread;

Thread Threads[2];     //Space for our simple threads. Just 2!
int CurrentTask = -1;  //The thread currenlty running (-1 == none)

_irq0:
cli    ;Disable interrupts
 push 0 ;Push IRQ number
 push 0 ;Push dummy error code
 jmp IRQ_CommonStub

.. ;Other IRQS are here, similiar to above

IRQ_CommonStub:
 pusha          ;Push all standard registers
 push ds        ;Push segment d
 push es        ;Push segmetn e
 push fs        ; ''
 push gs        ; ''

 mov eax, 0x10  ;Get kernel data segment
 mov ds, eax    ;Put it in the data segment registers
 mov es, eax
 mov fs, eax
 mov gs, eax

 push esp       ;Push pointer to all the stuff we just pushed
 call _IRQ_Handler ;Call C code

 pop gs         ;Put the data segments back
 pop fs
 pop es
 pop ds

 popa           ;Put the standard registers back

 add esp, 8     ;Take the error code and IRQ number off the stack

 iret           ;Interrupt-Return

_irq0:
 ;Notice there is no IRQ number or error code - we don't need them

 pusha          ;Push all standard registers
 push ds        ;Push segment d
 push es        ;Push segmetn e
 push fs        ; ''
 push gs        ; ''

 mov eax, 0x10  ;Get kernel data segment
 mov ds, eax    ;Put it in the data segment registers
 mov es, eax
 mov fs, eax
 mov gs, eax

 push esp       ;Push pointer to all the stuff we just pushed
 call _TaskSwitch ;Call C code

 mov esp, eax   ;Replace the stack with what the C code gave us

 mov al, 0x20   ;Port number AND command number to Acknowledge IRQ
 out al, al     ;Acknowledge IRQ, so we keep getting interrupts

 pop gs         ;Put the data segments back
 pop fs
 pop es
 pop ds

 popa           ;Put the standard registers back

 ;We didn't push an error code or IRQ number, so we don't have to edit esp now

 iret           ;Interrupt-Return

//This will create a task
//It will make a stack that looks like it has all
//of the stuff of an IRQ handler 'pushed' on it
void CreateTask(int id, void (*thread)()){
  unsigned int *stack;
  Threads[id].esp0 = AllocPage() + 4096; //This allocates 4kb of memory, then puts the pointer at the end of it

  stack = (unsigned int*)Threads[id].esp0; //This makes a pointer to the stack for us

  //First, this stuff is pushed by the processor
  *--stack = 0x0202; //This is EFLAGS
  *--stack = 0x08;   //This is CS, our code segment
  *--stack = (UINT)thread; //This is EIP

  //Next, the stuff pushed by 'pusha'
  *--stack = 0; //EDI
  *--stack = 0; //ESI
  *--stack = 0; //EBP
  *--stack = 0; //Just an offset, no value
  *--stack = 0; //EBX
  *--stack = 0; //EDX
  *--stack = 0; //ECX
  *--stack = 0; //EAX

  //Now these are the data segments pushed by the IRQ handler
  *--stack = 0x10; //DS
  *--stack = 0x10; //ES
  *--stack = 0x10; //FS
  *--stack = 0x10; //GS
  Threads[id].esp0 = (UINT)stack; //Update the stack pointer
}

//Switch between our two tasks
//Notice how we get the old esp from the ASM code
//It's not a pointer, but we actually get the ESP value
//That way we can save it in our task structure
unsigned int TaskSwitch(unsigned int OldEsp){
if(CurrentTask != -1){ //Were we even running a task?
 Threads[CurrenTask].esp0 = OldEsp; //Save the new esp for the thread

 //Now switch what task we're on
 if(CurrentTask == 0)CurrentTask = 1;
 else CurrentTask = 0;
} else{
 CurrentTask = 0; //We just started multi-tasking, start with task 0
}
 return Threads[CurrentTask].esp0; //Return new stack pointer to ASM
}

extern void irq0(); //Our ASM stub
//This is a very simple function
//All it does is put us in the IDT
void StartMultitasking(){
IdtSetGate(0, (UINT)irq0); //Install us in IDT. We multitask NOW!
}

//These are just two simple functions that act as
//'threads' to test our multi-tasker on
//I won't try to explain how they work
//Only that they change colors on two letters of the screen

//Also - they must NEVER return - just make an infinite loop

void ThreadTest1(){
unsigned char* VidMemChar = (unsigned char*)0xB8001;
for(;;)*VidMemChar++;
}

void ThreadTest2(){
unsigned char* VidMemChar = (unsigned char*)0xB8003;
for(;;)*VidMemChar++;
}

CreateTask(0, ThreadTest1); //Install the first task
CreateTask(1, ThreadTest2); //Install the second task
StartMultitasking(); //Start your multitasking OS!
//We're now multitasking. Celebrate!
